Durma PBH 100

Durma PBH 100

Shaft Diameter – Top: 4.33″ (110mm)
Shaft Diameter – Planetary (2) 3.94″ (100mm)
Roll Diameters: 12.4″
Motor Power: 15 HP
Turning Speed: 0 – 26 FPM
Dimensions: 69″ L x 53″ W x 65″ H
Weight: 7392 lbs.

STANDARD SPECIFICATIONS:• 1 set of standard universal hardened and ground rolls (special steel)
• All three rolls (shafts) are hydra motor driven through planetary gear box
• 3-axis hardened side supports (lateral guide rolls) with hydraulic forward-backward movement (Thrust → ) and mechanical up-down and right-left movement
• Side supports will accommodate leg-in / leg-out angle iron bending
• Portable control panel with programmable DROs
• Vertical or horizontal operation
• Body constructed of stress-relieved steel
• Hydraulic/electrical overload protection
• Bottom roll shafts hydraulically adjusted
• World standard electrical/hydraulic components (parts stocked by us or available off-the-shelf from your local supplier)
• Compliant with CE norms regulations

OPTIONS:• Special rolls for tubes, profiles,etc.
• Rolls and tooling for hardway beam/channel bending
• Adjustable turning speed
• Hydraulic control of lateral guide rolls in additional 2 axes (Translation ↑ / Radial σ )
• Digital readout for side supports
• NC control system – with or without axis
• CNC control system
• Remote (wired or wireless)
• Special apparatus to prevent deformation on U-I-H bending
• Spiral bending apparatus
